Product Details
Place of Origin: China
Brand Name: TC
Payment & Shipping Terms
Price: Negotiation
Product Name: |
MPO Fiber Optic Cable |
Jacket Material: |
PVC/LSZH |
Connector: |
LC |
Connector Type: |
Male/female |
Backbone Cable: |
OS2, OM3, OM4 |
Core Number: |
12 |
Outer Diameter: |
4.5mm/5.0mm |
Polarity: |
A/B |
Standards Met: |
GB/T 18233 (ISO/IEC 11801); GB 50311; |
MPO Grinding Type: |
UPC/APC |
Product Name: |
MPO Fiber Optic Cable |
Jacket Material: |
PVC/LSZH |
Connector: |
LC |
Connector Type: |
Male/female |
Backbone Cable: |
OS2, OM3, OM4 |
Core Number: |
12 |
Outer Diameter: |
4.5mm/5.0mm |
Polarity: |
A/B |
Standards Met: |
GB/T 18233 (ISO/IEC 11801); GB 50311; |
MPO Grinding Type: |
UPC/APC |
12 Core LC LC Breakout Cable 12 Fiber Fanout Cable Pre Terminated Fiber Cable Application
MPO Fiber Optic Cable Features
Pre-terminated Fiber Optic Cables adopt high-grade low-loss MPO/MTP and LC connectors and have a 100% pass guarantee on the polishing process, exceeding all parameters specified in IEC 61754, IEC 61755 standards.
Matched with Magic series patch panel and allied with pre-term cassettes, this product offers users the latest 10G-800G integrated solutions.
Pre-terminated Fiber Optic Cables provide fast deployment for horizontal and backbone fiber optic cables in equipment rooms of smart building cabling system as well as all data centers.
Standardized components, de-engineered, ensure data center production in factories and realize the overall delivery to customers. Customers can quickly acquire products as needed and expand capacity according to businesses.
MPO Fiber Optic Cable Application Standards
GB/T 18233 (ISO/IEC 11801); GB 50311; TIA/EIA568-C.2
MPO Fiber Optic Cable Technical Details
| Specifications | OM3/OM4 | OM5 | G.657.A2 PC | G.657.A2 APC | |
| LC Connector |
Connector Type, Grinding Type |
ZrO2 PC 0˚ | ZrO2 PC 0˚ | ZrO2 PC 0˚ | ZrO2 APC 8˚ |
| Insertion Loss IL (Typical) | ≤0.10dB | ≤0.10dB | ≤0.10dB | ≤0.10dB | |
| Insertion Loss IL (Max.) | ≤0.25dB | ≤0.25dB | ≤0.25dB | ≤0.25dB | |
| Return Loss RL (Typical) | ≥40dB | ≥40dB | ≥50dB | ≥75dB | |
| Return Loss RL (Min.) | ≥35dB | ≥35dB | ≥45dB | ≥65dB | |
| Color Code | Aqua /Violet | Lime green | Blue | Green | |
| Jacket Material | PEI | PEI | PEI | PEI | |
| Dust Cover (duplex) | White or Transparent | White or Transparent | White or Transparent | White or Transparent |
TC Smart Systems Group was established in 1988, and has grown into a national powerhouse in low voltage cables and cabling system.We provide all serials of cables and wiring for security systems, commercial buildings, metro lines, airport and many more. With annual output more than 230 million dollars, TC is known to those who are in this industry.
