Micro Modular Data Center TCRM Series Modular UPS 20-200kVA Rack Mounted

Name: Micro Modular Data Center TCRM Series Modular UPS 20-200kVA Rack Mounted
Brand: TC Smart Systems Group
SKU: TCRM 060/20
Availability: InStock

Product Details

Place of Origin: China

Brand Name: TC

Model Number: TCRM 060/20

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                Rack Mounted Micro Modular Data Center, 20-200kVA Micro Modular Data Center, TCRM Series Micro Modular Data Center


Wiring:	3 Phase + N + PE	Voltage:	380/400/415Vac
Frequency:	50/60Hz	Power Factor:	＞ 0.99
Current THDi:	＜ 3%	Range Of Voltage:	Default: -20% To +15%; Optional: -40% To +15%
Range Of Frequency:	40~70Hz	Battery Voltage:	±240VDC（32~44 Cells Adjustable）
Charging Power:	20%	Input Voltage:	380/400/415Vac

Wiring:	3 Phase + N + PE
Voltage:	380/400/415Vac
Frequency:	50/60Hz
Power Factor:	＞ 0.99
Current THDi:	＜ 3%
Range Of Voltage:	Default: -20% To +15%; Optional: -40% To +15%
Range Of Frequency:	40~70Hz
Battery Voltage:	±240VDC（32~44 Cells Adjustable）
Charging Power:	20%
Input Voltage:	380/400/415Vac

Micro Modular Data Center TCRM Series Modular UPS 20-200kVA Rack Mounted

Data Center TCRM Series Modular UPS 20 To 200kVA Rack Mounted Modular UPS

TCRM series modular UPS power, the industry leading, all-digital power distribution product, collects the most advanced technology in power electronics and automatic control, thus resulting in breakthrough improvements in power reliability, availability and maintainability of the critical equipment. It integrates the technical features of traditional tower-type with the need of modern modular server rooms, ensuring modular design together with high reliability of the system. It is widely used in government, finance, communications, education, transportation, meteorology, radio and television, industrial and commercial taxation, health care, energy and electricity and other sectors.


Wiring	3 phase + N + PE
Voltage	380/400/415Vac
Frequency	50/60Hz
Power Factor	＞ 0.99
Current THDi	＜ 3%
Range of Voltage	304~478Vac at full load,304V~228Vac linear derating
Range of Frequency	40~70Hz
Battery Voltage	±240VDC(32~44 cells adjustable)
Charging Power	20%
Input Voltage	380/400/415Vac
Range of Voltage	Default: -20% to +15%; Optional: -40% to +15%
Output Voltage	380/400/415VAC
Output Frequency	50/60Hz
Power Factor	0.9
Voltage Accuracy	±1%
Voltage THDv	＜ 1% (linear load) , ＜ 5.5% (nonlinear load)

Its core power device introduces an integrated packaging structure of IGBT modules for high input power factor. Its main body is equipped with a 5.7-inch LCD touchscreen for all-digital control, and with a hot-swapping static bypass monitoring module for remote EPO function. Highly efficient remote network management realizes "zero threshold" of maintenance. Smart battery management supports a cold start designed in redundancy module. Extra wide range of voltage input supports direct paralleling of cabinets.

Micro Modular Data Center TCRM Series Modular UPS 20-200kVA Rack Mounted 0

Micro Modular Data Center TCRM Series Modular UPS 20-200kVA Rack Mounted 1

Micro Modular Data Center TCRM Series Modular UPS 20-200kVA Rack Mounted 2

Micro Modular Data Center TCRM Series Modular UPS 20-200kVA Rack Mounted 3
