Product Details
Place of Origin: China
Brand Name: TC
Certification: GB/T 18233 (ISO/IEC 11801); GB 50311; TIA/EIA568.2-D
Model Number: HB-SJ
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Payment Terms: L/C, T/T, Western Union, MoneyGram
Size: |
173.5*38.5*29 |
Rack Unit: |
1U |
Material Of Outer Housing: |
High Strength ABS Material In Accordance With UL94V-0 |
Type Of Port: |
RJ45 Ports With 15 Microinches Golden Pins |
Compression Strength: |
AC700V Or DC1000V, No Breakdown Or Flashover For 1min |
Life Circle: |
≥ 750 Times |
Size: |
173.5*38.5*29 |
Rack Unit: |
1U |
Material Of Outer Housing: |
High Strength ABS Material In Accordance With UL94V-0 |
Type Of Port: |
RJ45 Ports With 15 Microinches Golden Pins |
Compression Strength: |
AC700V Or DC1000V, No Breakdown Or Flashover For 1min |
Life Circle: |
≥ 750 Times |
Multimedia Box Functional Accessories Direct-Connect 6-Port Data Module
| Specifications | |
| Size | 173.5*38.5*29 |
| Rack Unit | 1U |
| Material of Outer Housing | High strength ABS material in accordance with UL94V-0 |
| Type of Port | RJ45 ports with 15 microinches golden pins |
| Compression Strength | AC700V or DC1000V, no breakdown or flashover for 1min |
| Life Circle | ≥ 750 times |
| Resistance | Contact Resistance ≤ 20mΩ, Insulation Resistance ≥ 100MΩ |
| Temperature | Operation Temperature: -10℃ to 60℃ , Storage Temperature: -40℃ to 70℃ |
| Humidity | Operation Humidity: no coagulation at 10% to 90% RH, Storage Humidity: no coagulation at 5% to 90% RH |
| Performance | At and above Cat5e standards in YD/T 926.3 "Connecting Hardware Requirements for Generic Cabling", supporting 100MHZ network connection |
