Product Details
Place of Origin: China
Brand Name: TC
Model Number: PC-13-6A-10-TL-B
Payment & Shipping Terms
Minimum Order Quantity: 200 pcs
Price: Negotiable
Packaging Details: Seaworthy Packing
Delivery Time: 30000 pcs/month
Payment Terms: Western Union, T/T, L/C, MoneyGram
Type: |
CAT6A UTP |
Length: |
1m |
Color: |
Gray |
Conductor: |
7*0.16 |
No.of Conductors: |
8 |
Conductor Material: |
Bare Copper |
Sheath: |
LSZH |
Shape: |
Round |
Type: |
CAT6A UTP |
Length: |
1m |
Color: |
Gray |
Conductor: |
7*0.16 |
No.of Conductors: |
8 |
Conductor Material: |
Bare Copper |
Sheath: |
LSZH |
Shape: |
Round |
CAT6A UTP Patch Cord Application
Magic series, RJ45 Composite Patch Cord provides signal transmission in the telecommunications cabling, such as data, voice, audio, and images. When integrated with copper cables and jacks, it helps form the transmission channel for the structured cabling system and connects the information inlet/outlet and active devices (switches, computers, etc.).
TC's Magic series composite patch cord can be categorized as standard or ultrafine, including, but not limited to, high-performance general patch cord, patch cord with pull rod, patch cord with lock, and matched port lock.
The Cat6/Cat6a copper patch cord meets and even exceeds IEC 61935-2 standards. With bandwidth up to 350MHz (for Cat6 patch cord) and 600MHz (for Cat6a patch cord), coupled with Cat6/Cat6a links, it supports Class D/E/EA standard (for Cat6a patch cord) applications as well as the Ethernet applications, such as 10G Base-T, 5G Base-T, 2.5G Base-T, 1G Base-T, 1G Base-TX, and 100 Base-T. It also supports enhanced Power Over Ethernet (POE+) under IEEE 802.3at.
TC Patch Cord Features
Application Standards
GB/T 18233 (ISO/IEC 11801); GB 50311; TIA/EIA568-C.2
Technical Details
Mechanical Properties | |
Type/Length of Patch Cord | Stranded cable, standard length of 0.5m-20m, tailored product |
Life Cycle | ≥ 750 times |
Storage Temperature Range | -40℃ to +70℃ |
Installation Temperature Range | -10℃ to +60℃ |
Working Temperature Range | -20℃ to +60℃ |
Electrical Properties | |
Dielectric Strength | DC 1000V (AC 750V), no breakdown or flashover for 1 minute |
High-Frequency Performance | IEC 61935-2, 100% pass in-channel testing |
Power Over Ethernet (POE) | Enhanced Power Over Ethernet under IEEE 802.3at |
